Product dimensions

Table 1-11

Product dimensions with all doors closed and with toner cartridges and imaging drums

Product

Height

Depth

Width

Weight

M855dn

1003.3 mm (39.5 in)

736.6 mm (29 in)

723.9 mm (28.5 in)

85.2 kg (187.8 lb)

M855xh

1003.3 mm (39.5 in)

736.6 mm (29 in)

723.9 mm (28.5 in)

121.3 kg (267.4 lb)

M855x+

1003.3 mm (39.5 in)

736.6 mm (29 in)

723.9 mm (28.5 in)

124.2 kg (273.8 lb)

ENWW

HP Color LaserJet Enterprise M855 and HP Color LaserJet Enterprise flow MFP M880

19

background image

Figure 1-11

Product dimensions with all doors and trays closed

Table 1-12

Space requirements with all doors and trays fully opened

Product

Height

Depth

Width

M855dn

1003.3 mm (39.5 in)

1498.6 mm (59 in)

1244.6 mm (49 in)

M855xh

1003.3 mm (39.5 in)

1498.6 mm (59 in)

1244.6 mm (49 in)

M855x+

1003.3 mm (39.5 in)

1498.6 mm (59 in)

1244.6 mm (49 in)

Figure 1-12

Space requirements with all doors and trays fully opened

20

Chapter 1 Finishing accessory overview

ENWW

background image

Table 1-13

Accessory physical dimensions with all doors closed

Product

Height

Depth

Width

Weight

3x500 sheet feeder

387 mm (15.3 in)

699 mm (27.5 in)

711 mm (28 in)

36.1 kg (79.6 lb)

3,500-sheet high-

capacity input tray

387 mm (15.3 in)

699 mm (27.5 in)

711 mm (28 in)

39 kg (85.9 lb)

1x500 sheet feeder

(available in Europe,

the Middle East, and

Africa)

387 mm (15.3 in)

699 mm (27.5 in)

711 mm (28 in)

25.1 kg (55.3 lb)

Stapler/stacker

1003.3 mm (39.5 in)

736.6 mm (29 in)

571.9 mm (22.5 in)

60 kg (132.3 lb)

Stapler/stacker with

hole punch

1003.3 mm (39.5 in)

736.6 mm (29 in)

723.9 mm (28.5 in)

32 kg (136.7 lb)

Booklet maker

1003.3 mm (39.5 in)

736.6 mm (29 in)

571.9 mm (22.5 in)

60 kg (132.3 lb)

Booklet maker with

hole punch

1003.3 mm (39.5 in)

736.6 mm (29 in)

723.9 mm (28.5 in)

32 kg (136.7 lb)

Figure 1-13

Finishing accessory physical dimensions with all doors and trays closed

ENWW

HP Color LaserJet Enterprise M855 and HP Color LaserJet Enterprise flow MFP M880

21

background image

Figure 1-14

Finishing accessory with hole punch physical dimensions with all doors and trays closed

Table 1-14

Space requirement for the product and attached finishing accessory with all doors and trays fully opened

Product

Height

Depth

Width

Product and finishing accessory

without hole punch

1231.9 mm (48.5 in)

1498.6 mm (59 in)

2006.6 mm (79 in)

Product and finishing accessory

with hole punch

1231.9 mm (48.5 in)

1498.6 mm (59 in)

2159mm (85 in)

Figure 1-15

Space requirement for the product and attached finishing accessory with all doors and trays

fully opened

22

Chapter 1 Finishing accessory overview

ENWW

background image

Figure 1-16

Space requirement for the product and attached finishing accessory with hole punch with all

doors and trays fully opened
