3x500-sheet tray paper orientation
Use the following information to load paper in any of the trays in the 3x500-sheet feeder.
Table 3-18
3x500-sheet tray paper orientation
Paper type
Image orientation
Duplex mode
How to load paper
Preprinted or letterhead
Portrait
1-sided printing
Face-up
Top edge at the back of the tray
ENWW
Paper loading and orientation 101
Table 3-18
3x500-sheet tray paper orientation (continued)
Paper type
Image orientation
Duplex mode
How to load paper
Automatic 2-sided printing
Face-down
Top edge at the back of the tray
Landscape
1-sided printing
Face-up
Bottom edge toward the right side
of the tray
Automatic 2-sided printing
Face-down
Top edge toward the right side of
the tray
102 Chapter 3 Supported paper sizes and types for finishing accessories
ENWW
Table 3-18
3x500-sheet tray paper orientation (continued)
Paper type
Image orientation
Duplex mode
How to load paper
Prepunched
Portrait
1-sided printing
Holes toward the left side of the
tray
Automatic 2-sided printing
Holes toward the right side of the
tray
ENWW
Paper loading and orientation 103
104 Chapter 3 Supported paper sizes and types for finishing accessories
ENWW
